上次學過2D DP入門題目 Unique Path,接著來看進階一點的高度關聯延伸題
Unique Path II,這次板子上多了障礙物。
題目給定我們一個棋盤的高與寬,起點固定在左上角,終點固定在右下角。
每一步只能選擇往右走一格,或者往下走一格,不能回頭。
有障礙物的格子無法通過。
要求我們求出從起點到終點有幾條路徑。
測試範例:
Example 1:
Input: obstacleGrid = [[0,0,0],[0,1,0],[0,0,0]]
Output: 2
Explanation: There is one obstacle in the middle of the 3x3 grid above.
There are two ways to reach the bottom-right corner:
1. Right -> Right -> Down -> Down
2. Down -> Down -> Right -> Right
Example 2:
Input: obstacleGrid = [[0,1],[0,0]]
Output: 1
約束條件:
Constraints:
m == obstacleGrid.length
n == obstacleGrid[i].length
1 <= m, n <= 100
obstacleGrid[i][j]
is 0
or 1
.同樣地,先走過一遍解題框架可分為三大步驟,藉此鞏固解題基礎。
通常遇到這種棋盤式或者帶有點座標的題目,定義一個二維狀態的DP是一種很常見且直觀的選擇。
這裡,我們可以定義DP[x, y] 為從起點(0,0)到座標(x,y)的路徑數目(方法數)。
那麼,最後我們要計算的就是DP[終點x座標, 終點y座標] = DP[ n-1, m-1]
2. 定義狀態轉移關係式(通則) [我從哪裡來] => [答案從哪裡推導而來]
不難發現,除了最上面的那一條row,和最左的那一條column之外,
中間的點座標都有兩種選擇(往右或往下),反過來說,
中間的點座標可以從上面走過來,或者從左邊走過來。
所以,推廣到一般化的通式,對點座標(x, y)而言
DP[ x, y]
= 從起點左上角(0, 0)到點座標(x, y)的方法數
= 從起點左上角(0, 0)到點座標(x-1, y)的方法數 + 從起點左上角(0, 0)到點座標(x, y-1)的方法數
= DP[x-1, y] + DP[x, y-1]
3. 釐清初始狀態(終止條件) [第一步怎麼走,怎麼出發的]
有幾個情況是初始條件,或稱為遞迴的終止條件。
當點座標為(0, 0)起點時,顯然,方法只有一種
DP(0, 0) = 1
另外,當座標超出板子的邊界,落在界外,方法數只有零種
DP[x, y] = 0, if x, y 在界外
同理,當座標上有障礙物時,無法通過,方法數也只有零種
DP[x, y] = 0, if x, y 上有障礙物
到這裡,已經填滿解題框架的所有內容,接著我們把它轉成程式碼,
這裡以Python作為示範
Top down 2D DP程式碼:
class Solution:
def uniquePathsWithObstacles(self, obstacleGrid):
can_walk = lambda x, y: (1 - obstacleGrid[y][x] )
# height and width of matrix
h, w = len(obstacleGrid), len(obstacleGrid[0])
# DP table
dp = {}
def walk(x, y):
if (x, y) in dp:
# look-up DP table
return dp[x, y]
if not 0 <= x < w or not 0 <= y < h or not can_walk(x, y) :
# out-of-board, or cannot walk through
dp[x, y] = 0
return 0
if (x, y) == (0, 0):
# Starting point, aka base case
dp[x, y] = 1
return 1
# General cases
dp[x, y] = walk(x-1, y) + walk(x, y-1)
return dp[(x, y)]
# -------------------------------------
return walk(w-1, h-1)
時間複雜度:
O( m * n ),板子上的每個格子點都拜訪一次。
空間複雜度:
O( m * n ),板子上總共有O(m * n)個格子點,也是DP table的大小。
Bottom up 2D DP + Space optimization 空間優化 程式碼:
class Solution:
def uniquePathsWithObstacles(self, obstacleGrid):
allow_to_visit = lambda x, y: (1 - obstacleGrid[y][x] )
# height and width of matrix
h, w = len(obstacleGrid), len(obstacleGrid[0])
if h * w == 0 or not allow_to_visit(0, 0):
# Quick response for invalid cases
return 0
# update [0][0] as start point with one valid path
obstacleGrid[0][0] = 1
## base case: leftmost column
for y in range(1, h):
obstacleGrid[y][0] = obstacleGrid[y-1][0] * allow_to_visit(0, y)
## base case: top row
for x in range(1, w):
obstacleGrid[0][x] = obstacleGrid[0][x-1] * allow_to_visit(x, 0)
## general cases
for y in range(1, h):
for x in range(1, w):
# update path count from left and top
obstacleGrid[y][x] = (obstacleGrid[y][x-1] + obstacleGrid[y-1][x]) * allow_to_visit(x, y)
return obstacleGrid[h-1][w-1]
時間複雜度:
O( m * n ),板子上的每個格子點都拜訪一次。
空間複雜度:
O( 1 ),已經使用空間優化,in-place update,沒有建立額外的2D DP Table。
學完這題之後,吸收沉澱一下,記得和系列題的第一題 Unique Path 做一個對照,背後的2D DP 演算法建構 和 Path Count 路徑計算的模型,都是高度相似的。
Reference:
[1] Python/Go O(mn) by DP [w/ Hint] - Unique Paths II - LeetCode
