WPF 筆記 | Adorner ListView舉例

成果

成果展示

應用需求

使用者在操作時提示給使用者會插入的位置。

實作

1.建立控制元件ListView

使用使用到拖曳需要將Drop的功能開啟。

<ListView
    AllowDrop="True"
    MouseMove="ListView_MouseMove"
    DragDrop.Drop="ListView_Drop"
    DragDrop.DragOver="ListView_DragOver">
    <ListViewItem Content="Item1" Padding="0 10"/>
    <ListViewItem Content="Item2" Padding="0 10"/>
    <ListViewItem Content="Item3" Padding="0 10"/>
    <ListViewItem Content="Item4" Padding="0 10"/>
</ListView>

2.實作 DragListViewItemAdorner

重新覆寫(override)繪製方法，在需要插入的位置的地方繪製一條線提示使用者。

/// <summary>
/// 拖曳ListViewItem時產生的繪圖
/// </summary>
public class DragListViewItemAdorner : Adorner
{
    /// <summary>
    /// 插入此元件的上面或下面位置
    /// </summary>
    public AlignmentY DragAlign = AlignmentY.Bottom;

    public DragListViewItemAdorner(UIElement adornedElement) : base(adornedElement) { }
    public DragListViewItemAdorner(UIElement adornedElement, AlignmentY align) : base(adornedElement)
    {
        DragAlign = align;
    }
    protected override void OnRender(DrawingContext drawingContext)
    {
        Rect adornedElementRect = new Rect(this.AdornedElement.RenderSize);
        Pen renderPen = new Pen(new SolidColorBrush(Colors.Navy), 1.5);
        if (DragAlign == AlignmentY.Bottom)
            drawingContext.DrawLine(renderPen, adornedElementRect.BottomLeft, adornedElementRect.BottomRight);
        else if (DragAlign == AlignmentY.Top)
            drawingContext.DrawLine(renderPen, adornedElementRect.TopLeft, adornedElementRect.TopRight);
    }
}

3.拖曳定義

設定拖曳的是ListViewItem時才會有效果。

private void ListView_MouseMove(object sender, MouseEventArgs e)
{
    if (e.LeftButton == MouseButtonState.Pressed)
    {
        if (sender is ListView LVControl && LVControl.SelectedItem != null)
        {
            DragDrop.DoDragDrop(LVControl, LVControl.SelectedItem, DragDropEffects.Move);
        }
    }
}

4.拖曳時的事件

鼠標移動時偵測是否停留在ListViewItem上若不是則會改變鼠標圖示，若停留在ListViewItem上則會判斷該插入的是此ListViewItem的上面或下面位置。

private void ListView_DragOver(object sender, DragEventArgs e)
{    Point currentPosition;
    AlignmentY alignY;
    e.Effects = DragDropEffects.None;

    if (e.Data.GetData(typeof(ListViewItem)) is ListViewItem el)
    {
        if ( e.Source is ListViewItem selectItem)
        {
            currentPosition = e.GetPosition(selectItem);
            alignY = currentPosition.Y > (selectItem.ActualHeight / 2) ? AlignmentY.Bottom : AlignmentY.Top;
            e.Effects = DragDropEffects.Move;
            SetElementAdorner(selectItem, alignY);
        }
        else
        {
            RemoveElementAdorner();
        }
    }
}

5.拖曳完成事件

檢查選取的Item與插入的item是否不同，則會判斷該插入的位置進行插入。

private void ListView_Drop(object sender, DragEventArgs e)
{
    if (e.Data.GetData(typeof(ListViewItem)) is ListViewItem el)
    {
        if( e.Source is ListViewItem selectItem)
        {
            ListView lvControl = (ListView)sender;
            if (selectItem != el)
            {
                // 改變控建順序
                AlignmentY alignY;
                int i1, i2, diff;
                i1 = lvControl.Items.IndexOf(el);
                i2 = lvControl.Items.IndexOf(selectItem);
                alignY = GetElementAdornerAlignmentY(el);
                if(alignY != AlignmentY.Center)
                {
                    diff = i2 > i1 ? 1 : -1;
                    if (i1 >= 0 && i2 >= 0)
                    {
                        ListViewItem item1;
                        item1 = (ListViewItem)lvControl.Items[i1];
                        lvControl.Items.RemoveAt(i1);
                        if (i2 > i1)
                        {
                            if (alignY == AlignmentY.Top)
                                lvControl.Items.Insert(i2 - 1, item1);
                            else if (alignY == AlignmentY.Bottom)
                                lvControl.Items.Insert(i2, item1);
                        }
                        else
                        {
                            if (alignY == AlignmentY.Top)
                                lvControl.Items.Insert(i2, item1);
                            else if (alignY == AlignmentY.Bottom)
                                lvControl.Items.Insert(i2 + 1, item1);
                        }
                    }
                }
            }
        }
        RemoveElementAdorner();
    }
}

6.Adorner 相關方法

取得目前該插入的位置,設置方法和移除方法。

private UIElement AdornerElement;

/// <summary>
/// 取得 Adorner的插入位置
/// </summary>
private AlignmentY GetElementAdornerAlignmentY(UIElement el)
{
    AdornerLayer elAdornerLayer = AdornerLayer.GetAdornerLayer(el);
    Adorner[] AdronerLayers = elAdornerLayer.GetAdorners(AdornerElement);
    if (AdronerLayers != null)
    {
        if (AdronerLayers.Length > 0)
            if (AdronerLayers[0] is DragListViewItemAdorner adornerly)
                return adornerly.DragAlign;
    }
    return AlignmentY.Center;
}
/// <summary>
/// 設置 Adorner
/// </summary>
private void SetElementAdorner(UIElement el, AlignmentY align)
{
    AdornerLayer elAdornerLayer;
    if (el == AdornerElement && AdornerElement != null)
    {
        elAdornerLayer = AdornerLayer.GetAdornerLayer(AdornerElement);
        Adorner[] AdronerLayers = elAdornerLayer.GetAdorners(AdornerElement);
        if (AdronerLayers != null)
        {
            AlignmentY aligny = GetElementAdornerAlignmentY(AdornerElement);

            if (AdronerLayers.Length > 0)
            {
                if (AdronerLayers[0] is DragListViewItemAdorner adornerly)
                {
                    if (adornerly.DragAlign != align)
                    {
                        adornerly.DragAlign = align;
                        adornerly.InvalidateVisual();
                    }
                }
            }
        }
    }
    else
    {
        if (AdornerElement != null)
            RemoveElementAdorner();
        AdornerElement = el;

        elAdornerLayer = AdornerLayer.GetAdornerLayer(AdornerElement);
        if (elAdornerLayer != null)
            elAdornerLayer.Add(new DragListViewItemAdorner(AdornerElement, align));
    }
}
/// <summary>
/// 移除 Adorner
/// </summary>
private void RemoveElementAdorner()
{
    if( AdornerElement != null)
    {
        AdornerLayer elAdornerLayer = AdornerLayer.GetAdornerLayer(AdornerElement);
        Adorner[] AdronerLayers = elAdornerLayer.GetAdorners(AdornerElement);
        if (AdronerLayers != null)
        {
            for (int i = 0; i < AdronerLayers.Length; i++)
                elAdornerLayer.Remove(AdronerLayers[i]);
        }
        AdornerElement = null;
    }
}
