重啟撲克機器人之路：從Python開始的新嘗試

今天開始了新的撲克機器人Project，這次選擇用Python而不是OpenHoldem的C++。其實挺有趣的，以前總覺得要寫機器人是件很困難的事，但現在連我這種程式小白都能靠著插件和LLM寫出基本的框架，這讓我開始思考是不是能把機器學習也加進來。

目前用ADB和OpenCV來處理手機截圖和畫面識別，雖然都還很陽春，但至少驗證了可行性。不過下一步的撲克牌辨識就讓我陷入了思考 - 單純用OpenCV的template matching感覺太過脆弱，平台改版或換平台就得重來。想起之前上fast.ai課程時學過的圖像辨識，或許能用那個方向來處理卡牌識別。

策略核心這塊還在想該怎麼處理。之前的經驗告訴我，直接套用solver策略行不通，自己寫死的腳本又太容易被識破是機器人。這讓我意識到可能需要更靈活的方式，但目前還沒有明確的想法。決定先專注在最基礎的部分 - 確保程式能穩定連接到poker app並正確辨識桌面狀況。

想起之前做Pio bot和Spin bot的經驗，我更清楚知道這次要怎麼規劃開發流程。就像之前寫過的，初期投入成本要控制，要隨時準備接受feedback並調整方向。這次選擇Python作為開發語言，某種程度上也是降低入門門檻的選擇，讓我能更專注在核心邏輯而不是語言本身的學習上。

我用來截取template的code:

import cv2

import numpy as np

from ppadb.client import Client as AdbClient

import os



class CardTemplateCapture:

def __init__(self):

# Create output directory if it doesn't exist

self.output_dir = 'card_templates'

if not os.path.exists(self.output_dir):

os.makedirs(self.output_dir)

# Initialize ADB connection

self.adb = AdbClient(host="127.0.0.1", port=5037)

self.devices = self.adb.devices()

if not self.devices:

raise Exception("No devices found. Make sure your emulator is running.")

self.device = self.devices[0]

# Initialize variables for region selection

self.start_point = None

self.end_point = None

self.drawing = False

self.current_image = None

self.original_image = None

self.template_count = 0

# Set target display height (adjust this based on your screen)

self.target_height = 1200

def take_screenshot(self):

"""Take a screenshot and return both original and resized versions."""

screenshot_data = self.device.screencap()

nparr = np.frombuffer(screenshot_data, np.uint8)

self.original_image = cv2.imdecode(nparr, cv2.IMREAD_COLOR)

# Calculate scaling factor to fit screen height

scale = self.target_height / self.original_image.shape[0]

new_width = int(self.original_image.shape[1] * scale)

# Resize image for display

self.current_image = cv2.resize(self.original_image, (new_width, self.target_height))

return self.current_image.copy()

def get_scale_factor(self):

"""Calculate the scale factor between original and display images."""

return self.original_image.shape[0] / self.current_image.shape[0]

def mouse_callback(self, event, x, y, flags, param):

"""Handle mouse events for selecting regions."""

if event == cv2.EVENT_LBUTTONDOWN:

self.drawing = True

self.start_point = (x, y)

elif event == cv2.EVENT_MOUSEMOVE and self.drawing:

temp_img = self.current_image.copy()

cv2.rectangle(temp_img, self.start_point, (x, y), (0, 255, 0), 2)

cv2.imshow('Capture Cards', temp_img)

elif event == cv2.EVENT_LBUTTONUP:

self.drawing = False

self.end_point = (x, y)

# Calculate rectangle coordinates on display image

x1 = min(self.start_point[0], self.end_point[0])

y1 = min(self.start_point[1], self.end_point[1])

x2 = max(self.start_point[0], self.end_point[0])

y2 = max(self.start_point[1], self.end_point[1])

# Scale coordinates to original image size

scale = self.get_scale_factor()

orig_x1 = int(x1 * scale)

orig_y1 = int(y1 * scale)

orig_x2 = int(x2 * scale)

orig_y2 = int(y2 * scale)

# Extract and save the selected region from original image

if (orig_x2 - orig_x1) > 0 and (orig_y2 - orig_y1) > 0:

card = self.original_image[orig_y1:orig_y2, orig_x1:orig_x2]

filename = os.path.join(self.output_dir, f'card_{self.template_count}.png')

cv2.imwrite(filename, card)

print(f"Saved {filename}")

self.template_count += 1

def capture_templates(self):

"""Main loop for capturing templates."""

print("Instructions:")

print("1. Click and drag to select card regions")

print("2. Press 'r' to refresh screenshot")

print("3. Press 'q' to quit")

# Create window with scrollbars

cv2.namedWindow('Capture Cards', cv2.WINDOW_NORMAL)

cv2.resizeWindow('Capture Cards', 800, 1200) # Set initial window size

cv2.setMouseCallback('Capture Cards', self.mouse_callback)

# Initial screenshot

screen = self.take_screenshot()

cv2.imshow('Capture Cards', screen)

while True:

key = cv2.waitKey(50) & 0xFF

if key == ord('q'):

break

elif key == ord('r'):

print("Refreshing screenshot...")

screen = self.take_screenshot()

cv2.imshow('Capture Cards', screen)

cv2.destroyAllWindows()



def main():

try:

capturer = CardTemplateCapture()

capturer.capture_templates()

except Exception as e:

print(f"Error: {e}")



if __name__ == "__main__":

main()
