這篇文章,會帶著大家複習以前學過的二元搜尋樹(Binary Search Tree)框架,
並且以二分搜尋樹的概念與定義為核心,
貫穿一些相關聯的題目,透過框架複現來幫助讀者理解這個演算法框架。
左子樹的節點值一定都比根結點值還小。
右子樹的節點值一定都比根結點值還大。
所有子樹都遵循相同的遞回定義。
不論是新增節點、刪除節點、還是查詢節點,都必須滿足這個定義。
整個二元搜尋樹BST的結構可以用下方這個示意圖表示:
接下來,我們會用這個上面這種結構,貫穿一些同類型,有關聯的題目
(請讀者、或觀眾留意上面的這種 二元搜尋樹 框架,之後的解說會反覆出現)
在一個已知的二元搜尋樹,搜尋某個目標值。
依照定義出發即可,寫起來很像二元樹版本的Binary Search。
迭代版本的程式碼
class Solution:
def searchBST(self, root: TreeNode, val: int) -> TreeNode:
cur = root
while cur is not None:
if cur.val == val:
# hit
return cur
elif cur.val > val:
# val is smaller than current node value, serach left sub-tree
cur = cur.left
else:
# val is larger than current node value, serach right sub-tree
cur = cur.right
# miss
return None
遞回版本的程式碼
class Solution:
def searchBST(self, root: Optional[TreeNode], val: int) -> Optional[TreeNode]:
if not root:
return None
if val < root.val:
# val is smaller then root.val, search left subtree
return self.searchBST(root.left, val)
elif val > root.val:
# val is larger than root.val, search right subtree
return self.searchBST(root.right, val)
else:
# val is equal to root.val, this is answer
return root
在一個已知的二元搜尋樹,搜尋一個節點,帶有指定的值val。
和搜尋其實很像,也是利用二元搜尋樹已經排序的特性,來根據定義來尋找插入位置,接著放入新增的節點。
迭代版本的程式碼
class Solution:
def insertIntoBST(self, root: Optional[TreeNode], val: int) -> Optional[TreeNode]:
if not root: return TreeNode(val)
cur, next = None, root
while next:
cur = next
next = cur.left if val < cur.val else cur.right
if val < cur.val:
cur.left = TreeNode(val)
else:
cur.right = TreeNode(val)
return root
遞回版本的程式碼
class Solution:
def insertIntoBST(self, root: TreeNode, val: int) -> TreeNode:
## Base case
# Already found insertion place
if not root:
node = TreeNode( val )
return node
## General cases
# Insert with BST ordering rule
if val > root.val:
root.right = self.insertIntoBST(root.right, val)
else:
root.left = self.insertIntoBST(root.left, val)
return root
查詢、新增都複習了,接下來就是刪除節點。
前面提過,不論作哪一種操作,都要保持BST左邊小,右邊大的已排序性質。
那刪除之後,要找誰遞補這個空缺呢?
有兩個解,兩組都可以。
第一種: 選擇被刪除的節點的左子樹裡面的最大節點值。
第二種: 選擇被刪除的節點的右子樹裡面的最小節點值。
第一種解: 選擇被刪除的節點的左子樹裡面的最大節點值。
class Solution:
def deleteNode(self, root: TreeNode, key: int) -> TreeNode:
if not root:
return None
if root.val > key:
# Target node is smaller than currnet node, search left subtree
root.left = self.deleteNode( root.left, key )
elif root.val < key:
# Target node is larger than currnet node, search right subtree
root.right = self.deleteNode( root.right, key )
else:
# Current node is target node
if (not root.left) or (not root.right):
# At least one child is empty
# Target node is replaced by either non-empty child or None
root = root.left if root.left else root.right
else:
# Both two childs exist
# Target node is replaced by largest element of left subtree
cur = root.left
while cur.right:
cur = cur.right
root.val = cur.val
root.left = self.deleteNode( root.left, cur.val )
return root
第二種解: 選擇被刪除的節點的右子樹裡面的最小節點值。
class Solution:
def deleteNode(self, root: TreeNode, key: int) -> TreeNode:
if not root:
return None
if root.val > key:
# Target node is smaller than currnet node, search left subtree
root.left = self.deleteNode( root.left, key )
elif root.val < key:
# Target node is larger than currnet node, search right subtree
root.right = self.deleteNode( root.right, key )
else:
# Current node is target node
if (not root.left) or (not root.right):
# At least one child is empty
# Target node is replaced by either non-empty child or None
root = root.left if root.left else root.right
else:
# Both two childs exist
# Target node is replaced by smallest element of right subtree
cur = root.right
while cur.left:
cur = cur.left
root.val = cur.val
root.right = self.deleteNode( root.right, cur.val )
return root
好,今天一口氣介紹了最精華的部分,
通用的Binary search Tree 二元搜索樹的框架,
還有相關的衍伸變化題與演算法建造流程,
希望能幫助讀者、觀眾徹底理解它的原理,
並且能夠舉一反三,洞察其背後的本質!
感謝收看囉! 我們下篇文章再見~
